Detector Operation
2–14 AA5348 | 2012-12-20
DRX Detector LED Display Matrix
LED Pattern The meaning of the LED Pattern. The action the user should take.
1 Green Flash The detector is in Standby, and no
study is active. The Console may
not be connected, or the power is
low.
No action is required. The detector
is not being used.
2 Green Flashes The System is on, and in Ready
status.
No action is required. The LED
indicates that the detector has
been selected.
3 Green Flashes The System is on and enabled, but
not ready.
This should not display in normal
operation. If this pattern is visible,
call Service.
4 Green Flashes The System is on and enabled.
These flashes appear while press-
ing the prep switch.
No action is required.
5 Green Flashes A power fault has occurred. The
detector is unusable.
Remove and re-insert the battery
to clear the problem. If the prob-
lem persists, call Service.
1 Blue Flash The detector is currently con-
nected to the System Console.
No action is required.
2 Blue Flashes The detector is not currently con-
nected to the System Console.
If this pattern occurs while detec-
tor is in use, call Service.
3 Blue Flashes The detector has rebooted and
has not yet connected to the Sys-
tem Console.
If this pattern occurs when the
detector should be in use, call Ser-
vice.
4 Blue Flashes The detector is performing a firm-
ware upload.
Do not interact with the detector.
5 Blue Flashes The detector is attempting to con-
nect to the wireless Access Point
(AP).
No action is required.
