Technical Specifications
6-2 AF0118 | 2018-03-27
Collimator light
beam diaphragm
and visual aids
The collimator LBD source provides an average luminance 160 Lux at 100
cm.
Refer to CFR, Title 21, Volume 8, 1020.31, (d)(2)(ii).
Computer
Intel® Core™ Core i5 or better
OS: Windows
Memory: 8 GB minimum
I/O: 1 Ethernet, 2 USB ports
Storage: Can store up to 1700 images
Network: 10/100/1000 Gigabit Ethernet, IEEE 802.11 a/b/g/n Wireless
network
Detectors and
rechargeable
batteries
Storage space for one 43 x 43 cm, one 35 x 43 cm, and one 25 x 30 cm
digital flat panel detector. Storage space for one detector battery. The 35
x 43 detector can be coupled with the grid frame assembly when inserted
into bin. For detectors that are ISO 4090 compliant.
Generator
5.3 kW @ 100 msec; 7.7 kW @ 13 msec kW X-ray generator
kV range 40 – 110kV
mAs range 0.2 – 20.0 mAs
mA range 30 – 80 mA (not user-selectable)
Tube head assembly
(X-ray tube
head, yoke,
collimator)
Movement force
Vertical (zeta - z)
Horizontal (gamma)
Column rotation (beta)
Tube angulation (alpha)
Tube tilt (tau)
Holding force
Vertical (zeta)
Horizontal (gamma)
Column rotation (beta)
(alpha)
(tau)
53 N
3.5 lbf (15 N)
20 Nm
24 Nm
18 Nm
40 lbf (175 N)
20 lbf (93 N)
4 lbf (17 N)
26 N-m (230 in-lb)
28 N-m (250 in-lb)
X-ray tube and tube
movements
Tube range 40–110kV
Anode heat capacity 300 Khu
IEC Focal spots: [0.9 – 1.9] equivalent, 0.1 increments.
Target angle = 14 °
Angulation range (alpha)± 110 °
Tilt range (tau) –16 to +98 °(where zero = tube pointing straight down)
When the arm is fully extended, the X-ray tube focal spot is 2123 mm
from the floor
