BT2 user manual - H-5911-9004-02-B Page | 100
A list of all deployments in the active project is displayed. Each row in the list of deployments displays the Hole from
which the deployment was made, the Name of the deployment, the coordinates of the end of the deployment and
a Deploy button.
To view details of a deployment in the list, tap on the appropriate deployment to open the Deployment Details
window (see section 14.1.4).
To start a survey from the end of a specific deployment, tap the Deploy BT button next to the appropriate hole. You
may use this option if, for example, the Boretrak2 probe is still positioned in the hole at the end of a deployment
after the operation was interrupted due to power failure. Alternatively, if you return to the site of a previous
deployment, but do not wish to replicate the whole series of Boretrak readings, you can simply deploy down to the
same position and then commence operations from the bottom of the hole.
In the 3D View, the deployment is marked by a deployment graphic (see section 12.1).
14.1.5 Alignment tab
The Alignments tab lists the Boretrak2 alignments which have been carried out in the active project.
An Alignment marks an alignment event carried out during field operations.
Figure 106 Project Details > Deployments
Figure 107 Project Details > Alignments
