BT2 user manual - H-5911-9004-02-B Page | 20

Hole 2

Hole 1

Boretrak2 on

alignment jig

Heading computed

from hole 1 to hole 2

Steel cable attached

to Boretrak2 probe

Figure 11 The probe in the alignment jig aligned between two holes

Figure 12 Probe held in the alignment jig
