Carlson Boretrak2 User Manual

BT2 user manual - H-5911-9004-02-B Page | 49
To secure the wheels in place, insert and secure a clevis pin through the hole on each end of the axle.
Insert the handle into the connectors at the top of the frame. Ensure the holes in the handle are aligned with the
holes in the frame.
Clevis pin
Figure 56 Assembling the push rod system - step 5
Handle slotted
into connectors
Figure 57 Assembling the push rod system - step 6
