BT2 user manual - H-5911-9004-02-B Page | 50
Insert a M6 x 40 mm screw through the holes in each connector. Secure the handle to the frame with a nut and
washer. Tighten the screw using a 5 mm hex key.
Thread the cable guide onto the brass connector.
Handle secured with
M6 x 40 mm bolt, nut
and washer sets
Figure 58 Assembly of the push rod system - step 7
Cable guide
Figure 59 Assembly of the push rod system - step 8
