Page | 37
Carlson Software
WebUI (connued)
The following dialogue window appears at the boom of the page.
Radio Channel: Select a channel from the channel table provided by your
dealer. The frequency, bandwidth, and transmit power (base only) is shown
next to the channel.
Radio Mode: The BRx7 supports PacCrest protocols (GMSK and 4FSK
modulaon), Satel protocols, and Trimtalk protocols. For a full list of
protocols, with descripons (FEC, Scrambling, over the air link rate, and
modulaon), please refer to Appendix C.
FEC: Forward Error Correcons
Radio Power: Transmit RTK correcons at 100mW, 200mW, 500mW, or
1W (dependent upon the radio sengs and restricons provided by your
dealer). This feature is only displayed when running as a base.
Working Mode
(connued)
