111
NOTES:
1. Compressor must-trip (M.T.) amps and RLA values are maximum figures.
2. LRA values for PW second winding = 1/2 the LRA -XL value.
3. 3-Pole XL circuit breakers shown, other 3-Pole XL alternates and 6-Pole PW breakers available. Terminal lugs for circuit breakers available in
package 06EA660152.
4. RLA value shown is determined by: circuit breaker must trip value ÷ 1.40. Use this recommended (and minimum) RLA value to determine name
plate stamping, minimum contactor sizing, and wire sizing. RECOMMENDED RLA FOR 06E COMPRESSORS EQUALS: MUST- TRIP (M.T.) OF
CARLYLE APPROVED OVERCURRENT DEVICE BEING USED ÷ 1.40.
5. Compressor operating amps at any specific condition can only be determined from a performance curve.
6. Ohm values for resistance are approximate and shown for reference purposes only. Motors from different vendors and motors of different efficien-
cies can differ up to 15% from data shown.
ALLOWABLE OPERATING RANGES
NOMINAL
VOLTAGE
MAXIMUM MINIMUM
208/230
460
575
400 (50 Hz)
200 (50 Hz)
254
529
661
460
230
187
414
518
342
180
