96
3.29 — Electrical Accessories
TERMINAL BOX PACKAGE - This consists of terminal
box, cover, and necessary mounting components.
TERMINAL LUG PACKAGE - The 06DA660095 package
consists of six, screw-on terminal lugs with set screws. The
HY85TB004 and HY85TB008 packages consist of one
terminal lug (six required per compressor).
TERMINAL PLATE JUMPER PACKAGE FOR 06E,
06CC 50 TO 99 Cfm - This package consists of jumper bars,
terminal nuts and instructions to interconnect terminal studs
for proper motor starting (PW or XL) and voltage.
NOTE: With 06E multi-volt (208/230/460) compressors, the 460-volt motor can be con-
nected only for across-the-line start. A compressor with a distinct 460-volt motor (or desig-
nated P/W) must be used for part-winding start.
TERMINAL
BOX
PACKAGE
NUMBER
TYPE COMPRESSOR USAGE AND SIZE
06DA660078
06DA660075
06DA660150
06EA660095
Drawn Steel
Fabricated
Fabricated
Drawn Steel
All 06D 2-cyl. (6” x 5-3/4”) (15.2 x 14.6 cm)
All 06D 4-cyl. (6” x 5”) (15.2 x 12.7 cm)
All 06D 6-cyl. and 06CC 16 to 37 Cfm (6” x 8”) (15.2 x 20.3 cm)
All 06E 4 and 6-cyl. compressors and
06CC 50 to 99 Cfm (7” x 7”) (17.8 x 17.8 cm)
TERMINAL LUG
PACKAGE
NUMBER
COMPRESSOR USAGE
06DA660095
HY85TB008
HY85TB004
All 06D and 06CC 16 to 41 Cfm
All 06E and 06CC 50 to 99 Cfm #4 to #8 Wire Size
All 06E and 06CC 50 to 99 Cfm #1 to #4 Wire Size
JUMPER
PACKAGE
NUMBER
USAGE
06EA660141
06EA660097
208/230/460 (triple voltage)
208/230/460/575 (distinct voltage)
