3.0 — COMPRESSOR AND PARTS DATA
3.1 — 06D Series Compressors - Physical Data (Page 1 of 2)
(a) Approximate condensing temperature ranges. CHECK ACTUAL PERFORMANCE DATA FOR ANY NEW APPLICATION ESPECIALLY AT OR
NEAR UPPER OR LOWER LIMIT: Low Temperature=70 to 120 F (21 to 49 C), Medium Temperature=80 to 130 F (27 TO 54 C) and High Temperature
(R-407A, C, F only) = 80 to 150 F (27 to 66 C).
(b) The 06DR 109 single phase compressor has a 3 HP (2.2 kW) motor.
(c) Service compressors have dual suction service valve locations, one on motor end and one near the oil pump.
CARRIER/
CARLYLE
MODEL
NUMBER
STANDARD
SERVICE
REPLACEMENT
MODEL
SUCTION TEMPERATURE RANGE ...(a)
R-404A/507, R-448A and R-449A R-134a R-407A, R-407C and R-407F
Deg. F Deg. C Deg. F Deg. C Deg. F Deg. C
06DM8080... 06DM8086... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR1090... 06DR1096...(b) –40 to 0 –40 to –18 –10 to 55 –23 to 13 –35 to 0 –37 to –18
06DR0130... 06DR0136...(c) –40 to 0 –40 to –18 –10 to 55 –23 to 13 –35 to 0 –37 to –18
06DM3130... 06DM3136...(c) 0 to 50 –18 to 0 — — 0 to 55 –18 to 7
06DR3160... 06DR3166...(c) –40 to 25 –40 to –4 –10 to 55 –23 to 13 –35 to 25 –37 to –4
06DM3160... 06DM3166...(c) 0 to 25 –18 to –4 –10 to 55 –23 to 13 0 t
o 55 –18 to 7
06DR7180... 06DR7186... –40 to 0 –40 to –18 –10 to 55 –23 to 13 –35 to 0 –37 to –18
06DA8182... 06DA8186... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR8200... 06DR8206... –40 to 40 –40 to 4 –10 to 55 –23 to 13 –40 to 25 –40 to –4
06DR7240... 06DR7246... –40 to 25 –40 to 4 –10 to 55 –23 to 13 –40 to 25 –40 to –4
06DA8242... 06DA8246... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR7250... 06DR7256... –40 to 25 –40 to 4 –10 to 55 –23 to 13 –40 to 25 –40 to –4
06DA8252... 06DA8256... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR2280... 06DR2286... –40 to 25 –40 to 4 –10 to 55 –23 to 13 –40 to 25 –40 to –4
06DA3282... 06DA3286... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR3370... 06DR3376... –40 to 25 –40 to 4 –10 to 55 –23 to
13 –30 to 25 –40 to –4
06DM3370... 06DM3376... 0 to 25 –18 to 10 –10 to 55 –23 to 13 0 to 45 –18 to 7
06DA5342... 06DA5376... 0 to 50 –18 to 10 — — 0 to 55 –18 to 13
06DR5410... 06DR5416... –40 to 25 –40 to 4 — — –40 to 25 –40 to –4
