Carlyle 06E - Electromechanical Overcurrent Protection

115
4.9 — 06D Electromechanical Overcurrent Protection
* Voltage is 3 phase 60 cycle, unless noted as single-phase 60 cycle.
† Two overloads in parallel in legs 1 and 3.
NOTES:
1. Most 06D compressors have internal thermostat installed in motor and wire across terminals 8 and
9 at the terminal block. It trips (opens) control circuit at 221 F (105 C) and resets at 181 F (83 C).
2. Based on new high efficiency (H.E.) extended voltage compressor models.
3. Information in shaded area is no longer available in standard factory production.
COMPRESSOR
SIZE
VOLTAGE* CARLYLE NO. T.I. NO. REMARKS
06DR109
208/230-1-60
HN69GZ025
HN69GZ032
8347A23-31
8347A23-42
Common Start
06DM808
06DR013
208/230-1-60
HN69GZ024
HN69GZ014
8347A23-63
8347A23-53
Common Start
06DM313
06DM316
06DR316
06DR718
208/230-1-60
HN69GZ106
HN69GZ037
8348A7-4
8347A23-40
Common Start
06DR109
208/230
HN69GZ007 8347A23-54 2 Required
460 HN69GZ015 8347A23-92 2 Required
575 HN69GZ011 8347A23-86 2 Required
06DM808
06DR013
208/230 HN69GZ053 8347A23-19 2 Required
460 HN69GZ012 8347A23-56 2 Required
575
HN69GZ012 8347A23-56 2 Required
06DM313
06DM316
06DR316
06DR718
208/230 HN69GZ024 8347A23-63 2 Required
460 HN69GZ014 8347A23-53 2 Required
575 HN69GZ032 8347A23-42 2 Required
06DA818
06DR820
06DR724 (25)
208/230 HN69GZ214 8348A17-9 2 Required
460 HN69GZ038 8347A23-18 2 Required
575 HN69GZ037 8347A23-40 2 Required
06DA824 (25)
06DR228
208/230
HN69GZ306 8348B19-13 2 Required
460 HN69GZ010 8347A23-29 2 Required
575 HN69GZ053 8347A23-19 2 Required
06DA328
06DM337
06DR337
208/230 HN69GZ309 8348B19-11 3 Required
460 HN69GZ024 8347A23-63 2 Required
575 HN69GZ025 8347A23-31 2 Required
06DA537
06DR541
208/230 HN69GZ214 8348A17-9 4 Required†
460
HN69GZ106 8348A7-4 2 Required
575 HN69GZ301 8347A30-69 2 Required
