NOTES:
1. RLA (rated load amps) value shown for new high efficiency models is MCC ÷ 1.56 = RLA. Use this recommended (and minimum) RLA value to
determine nameplate stamping. Minimum contactor sizing and wire sizing.
2. Compressor operating amps at any specific condition can only be determined from a performance curve.
3. RLA values for 06D compressor protected by a calibrated circuit breaker will depend on must-trip value of circuit breaker.
4. Ohm values for resistance are approximate and shown for reference purposes only. Motors from different vendors and motors of different efficien-
cies can differ up to 15% from data shown.
ALLOWABLE OPERATING RANGES
NOMINAL
VOLTAGE
MAXIMUM MINIMUM
208/230
460
575
400 (50 Hz)
200 (50 Hz)
254
529
661
460
230
187
414
518
342
180
