CUSTOMER MODEL NUMBER CHANGES:
The 10th digit of the 06D customer model number will indi-
cate the rated control voltage of the electronic overcurrent
protection module that is applied. Three new customer mod-
els will replace each existing 06D model. Please see the fol-
lowing examples of the 06D customer model number
changes.
Example of 06D compressor model number change:
The 5th digit of the 06CC customer model number model
will indicate the rated control voltage of the electronic over-
current protection module that is applied. Three new cus-
tomer models will replace each existing 06CC model. Please
see the following examples of the 06CC customer model
number changes.
Example of 06CC compressor model number change:
NOTE: There is no change to the compressor electrical data
(LRA or MCC/RLA) with this change in motor protection.
SERVICE REPLACEMENT KITS:
The below kits are intended to service Carlyle 06D and
06CC (16-37 Cfm) compressors manufactured AFTER
August 2015, S/N starting with '3115', with the factory
installed electronic overcurrent protection. When selecting
06DR337SDA365A o 06DR337SD1365A [120/240VAC Control Voltage]
06DR337SDA
365A o 06DR337SD2365A [24VAC Control Voltage]
06DR337SDA
365A o 06DR337SD3365A [24VDC Control Voltage]
06CC1
25D2S1 o 06CCD25D2S1 [120/240VAC Control Voltage]
06CC1
25D2S1 o 06CCE25D2S1 [24VAC Control Voltage]
06CC1
25D2S1 o 06CCF25D2S1 [24VDC Control Voltage]
