SERVICE RETROFIT KITS (THREE PHASE):
The below kits are intended to service Carlyle 06D and
06CC (16-37 Cfm) compressors manufactured BEFORE
August 2015, S/N starting with '3115', with the factory
installed electromechanical overcurrent protection and a
three phase motor. The provided service kits are for RET-
ROFIT of an existing compressor with the electromechani-
cal overcurrent protection to the electronic overcurrent
protection scheme. When selecting the appropriate kit,
please be sure to select the required control voltage, as the
retrofit module will require OEM customers to provide con-
trol voltage to the terminal box of the compressor. All kits
include a replacement large folded terminal box, electronic
overcurrent protection module and current transformer, with
a preprogrammed MCC value based on the compressor
model number. For additional information on the kit and
installation, please see 99TA516184A located on the Car-
lyle Compressor website (www.carlylecompressor.com).
COMPRESSOR
MODEL NUMBER
ELECTRONIC OVERCURRENT PROTECTION
SERVICE RETROFIT (THREE PHASE) KIT NUMBER
MCC
Control Voltage
110-220V 24V AC 24V DC (Amps)
06C * 016D * * * 06DA6606DBSB0270 06DA6606DBSC0270 06DA6606DBSD0270 27.0
06C * 016G * * * 06DA6606DBSB0135 06DA6606DBSC0135 06DA6606DBSD013513.5
06C * 016J * * * 06DA6606DBSB0108 06DA6606DBSC0108 06DA6606DBSD0108 10.8
06C * 017D * * * 06DA6606DBSB0270 06DA6606DBSC0270 06DA6606DBSD0270 27.0
06C * 017G * * * 06DA6606DBSB0135 06DA6606DBSC0135 06DA6606DBSD013513.5
06C * 017J * * * 06DA6606DBSB0108 06DA6606DBSC0108 06DA6606DBSD0108 10.8
06C * 018D * * * 06DA6606DBSB0270 06DA6606DBSC0270 06DA6606DBSD0270 27.0
06C * 018G * * * 06DA6606DBSB0135 06DA6606DBSC0135 06DA6606DBSD013513.5
06C * 018J * * * 06DA6606DBSB0108 06DA6606DBSC0108 06DA6606DBSD0108 10.8
06C * 124D * * * 06DA6606DBSB0330 06DA6606DBSC0330 06DA6606DBSD0330 33.0
06C * 124G * * * 06DA6606DBSB0165 06DA6606DBSC0165 06DA6606DBSD0165 16.5
06C * 124J * * * 06DA6606DBSB0132 06DA6606DBSC0132 06DA6606DBSD013213.2
06C * 125D * * * 06DA6606DBSB0440 06DA6606DBSC0440 06DA6606DBSD0440 44.0
06C * 125G * * * 06DA6606DBSB0220 06DA6606DBSC0220 06DA6606DBSD0220 22.0
06C * 125J * * * 06DA6606DBSB0176 06DA6606DBSC0176 06DA6606DBSD0176 17.6
06C * 228D * * * 06DA6606DBSB0416 06DA6606DBSC0416 06DA6606DBSD0416 41.6
06C * 228G * * * 06DA6606DBSB0209 06DA6606DBSC0209 06DA6606DBSD0209 20.9
