159
SERVICE TABLE
Use this service table to verify that the PWM valve is modu-
lating correctly per the applied voltage signal to the smart
controller.
SMART
CONTROLLER
06D, 06CC, 06M
COMPRESSOR
CAPACITY
PWM
VALVE
Demand Signal Input (vdc) Percentage Solenoid Coil Energized
(sec)
1.0 20% 6
1.5 30% 9
2.0 40% 12
2.5 50% 15
3.0 60% 18
3.5 70% 21
4.0 80% 24
4.5 90% 27
5.0 100% 30
