C³ SUCTION MANIFOLD
(TO LOW STAGE CYLINDERS)
1/4" LOW STAGE
INPUT PRESSURE
HIGH STAGE
INLET
INTERSTAGE
MANIFOLD
IF PORT NOT
AVAILABLE
TAP TUBING
HERE
IF AVAILABLE USE
PORT ON SERVICE
VALVE TO DESUPERHEAT
LIQUID INJECTION FITTING
PN 2TA1004
CONN. FROM SUBCOOLING
HEAT EXCHANGER OR PORT
TO DESUPERHEAT LOW
STAGE DISCHARGE
3/4-10 UNC
LIFTING LUG CONN.
(LUG NOT SUPPLIED)
NOTE: Bolt sizes and thread pitch: Compressors are built using English unit
bolts. The bolts have no exact metric equivalents. Therefore, to prevent possible
cross-threading, loose bolts, or damage to threaded portions of the casing,
comparable metric measurements are not included.
