The OPSS can be reset in three different ways:
• Disconnect the module from the power supply for 5 sec-
onds.
• Push the rest button.
• Reset by operating recognition signal (D1), violet wire
for 5 seconds.
Once the module is reset, the compressor is allowed to re-
start again after a 120 second time delay.
LED Flash Codes:
Flashing 10 times per second:
• Internal Error.
• Voltage Supply too low.
• Electrical unit not completely attached to sensor.
• Operating recognition on but relay still off.
Flashing 1 time per second:
• Reset Delay
Continuous Light:
• Oil Differential Pressure low.
OFF:
• Differential pressure OK, no error.
