Carrier 38MGR Series - DIMENSIONS AND CLEARANCES; Unit Dimensions and Clearances

4 Specifications subject to change without notice. 38MGR-04SM
DIMENSIONS
Table 3 — Dimensions
Fig. 1 — Size 18K
NOTE: Master valves are not available on the 18K unit.
UNIT SIZE
18 24 30 36 48
Height
in (mm) 27.6 (703) 31.89 (810) 31.89 (810) 52.48 (1333) 52.48 (1333)
Width
in (mm) 37.31 (948) 41.22 (1047) 41.22 (1047) 41.14 (1045) 41.14 (1045)
Depth
in (mm) 14.82 (376) 17.91 (455) 17.91 (455) 17.63 (448) 17.63 (448)
Weight-Net
lbs (kg) 105.8 (48) 149.9 (68) 156.5 (71) 221.6 (100.5) 223.8 (101.5)
