Carrier 38MGR Series - DISASSEMBLY INSTRUCTIONS: SIZE 18; Disassembly Steps for Size 18 Unit

72 Specifications subject to change without notice. 38MGR-04SM
DISASSEMBLY INSTRUCTIONS SIZE 18
No. Part name Procedures Remarks
1 Fan
assembly
How to remove the fan
assembly.
1) Turn off the air conditioner
and turn off the power
breaker.
2) Remove the screws (4) of
the air outlet grille.
3) Remove hex nut securing
the fan.
4) Remove the fan.
5) Remove the top cover
screws (3), and remove the
top cover.
Screws of top
