Carrier 38MGR Series - How to Remove the Expansion Valve

38MGR-04SM Specifications subject to change without notice. 79
DISASSEMBLY INSTRUCTIONS SIZE 18 (CONT)
7The
expansion
valve
How to remove the expansion
valve
2) Remove the electrical parts
per the “Electrial Parts”
section.
3) Remove the coils.
4) Detach the welded parts of
the expansion valves and
pipes.
Coils
Expansion
valves
1) Complete the steps in the
“Fan Assembly” and “Panel
Plate” sections.
