48
Steps
Procedure
Remove the screws retaining the front grille to the
front panel. Remove the front grille.
Remove the screws retaining the panel, lift it
upward to loosen the clasp on the right side, rotate
it to the left and then remove the front panel.
2.Remove front grille and front panel
Remove the screws retaining the left side panel
to the chassis, then remove the left side panel.
Front panel
2
1
3.Remove right and left side panels
Left Side Panel
2
1 Remove the screws retaining the right side
panel to the chassis, the valve support and the
electric box, then remove the right side panel.
Front grille
Right Side
Panel
To Next Page
