66
7 Assemble the disassembled main parts as per the reverse
disassembly order mentioned above
Assemble the disassembled main parts as per the
reverse disassembly order mentioned above and
energize the unit for trial test.
Steps Procedure
Steps Procedure
1. Disconnect the power cord
2. Disassemble the pipeline connected with compressor
Disassembly and Assembly of Compressor
Disconnect the pipeline connected with compressor.
Remark: Make sure that there is no refrigerant in pipe system and the power supply is cut off before disassembling the compress or.
① Remove the fixed screws on the power cord by
using a screwdriver.
② Draw out the power cord;
Note:
Please note the color of each power cord and also
the corresponding terminal number when removing
the power cord in case of misconnection.
Note the color of
each power cord
and also the
corresponding
terminal
To Next Page
