PHYSICAL DATA -- 38GVM
Outdoor Unit 38GVM
218 324 430 436 542
System Voltage 208/230---1---60
Control Voltage Low Voltage Pulse DC
Rated Cooling Capacity (Btuh) 18,000 26,000 29,000 34,400 40,000
Cooling Cap. Range Min --- Max Btuh 7,000 --- 21,000 7,500 --- 33,000 7,500 --- 33,000 8,530 --- 34,000 8,500 --- 46,400
Rated Heating Capacity (Btuh) 19,000 29,000 30,400 37,200 43,000
Heating Cap. Range Min --- Max Btuh 2,500 --- 22,600 7,500 --- 35,000 7,500 --- 35,000 10,600 --- 40,900 10,600 --- 47,760
Operating Weight lb (kg) 95 (43) 135 (61.2) 137 (62.1) 161 (73) 225 (102.3)
Refrigerant Type R---410A
Metering Device (At Outdoor Unit) EXV
Charge lb (kg) 3.0 (1.4) 4.9 (2.2) 4.9 (2.2) 6.4 (2.9) 10.6 (4.8)
Compressor
Type Inverter Driven Rotary
Model SNB130FGYMC TNB220FLHMC TNB306FPGMC
Outdoor Fan
CFM hi/med/lo 1530 / 1354 / 942 1942 / 1707 / 1413 2177 (high) 3237 (high)
RPM hi/med/lo 830 / 670 / 500 690 / 600 / 500 820 / 640 / 560 860 / 650 / 550
Diameter (in) 17.5 20.5 21.7 22.4
Watts watts 60 120 140
Outdoor Coil
Face Area (sq. ft) 4.6 6.3 7.3 11.6
No. Rows 2
Fins per inch 18
Refrigerant Lines
Connection Type Flare
Liquid (Mix Phase) in OD (QTY) 1/4” (2) 1/4” (3) 1/4” (4) 1/4” (3), 3/8” (1) 1/4” (4), 3/8” (1)
Vapor Line in OD (QTY) 3/8” (2) 3/8” (3) 3/8” (4)
3/8” (2), 1/2” (1),
5/8”(1)
3/8” (2), 1/2” (2),
5/8”(1)
Total Piping ft. (m.)* 66 (20) 230 (70) 262 (80)
Max Piping to Any FCU ft. (m.) 33 (10) 66 (20) 82 (25)
Max Elevation (Between Indoors) 16.4 (5) 33 (10) 25 (7.5)
Max Lift (Fan Coil Above) ft 16.4 (5) 33 (10) 50 (15)
Max Drop (Fan Coil Below) ft 16.4 (5) 33 (10) 50 (15)
External Finish White
*Refer to Long Line Application section
