PHYSICAL DATA -- 40GVM
Indoor Unit 40GVM
009 012 018
System Voltage 208/230---1---60
Control Voltage Low Voltage Pulse DC
Electrical Connections Indoor Unit Powered From Outdoor Unit
Nominal Cooling Capacity (Btuh) 9,000 12,000 18,000
Nominal Heating Capacity (Btuh) 9,800 13,000 19,800
Operating Weight lb (kg) 22.0 (10) 29.0 (13)
Refrigerant Type R---410A
Metering Device (At Outdoor Unit) EXV
Moisture Removal Rate (pints/hr) 1.7 2.9 3.8
Indoor Fan
RPM/CFM (Super High) --- Cooling 1260 / 330 1280 / 341 1350 / 500
R P M / C FM ( H i gh ) --- C oo l i n g 1100 / 294 1100 / 277 1200 / 459
RPM/CFM (Medium) --- Cooling 950 / 253 950 / 253 1050 / 383
RPM/CFM (Low) --- Cooling 750 / 218 750 / 217 900 / 324
RPM/CFM (Super High) --- Heating 1320 / 330 1300 / 341 1420 / 500
RPM/CFM (High) --- Heating 1200 / 294 1170 / 277 1250 / 459
RPM/CFM (Medium) --- Heating 1100 / 253 1050 / 253 1150 / 383
R P M / C FM ( L o w ) --- He a t in g 750 / 218 950 / 217 1050 / 324
Motor Watts 20
Blower Quantity … Size in 1 … 3.6 x 25.4 1 … 3.9 x 27.9
Indoor Coil
Face Area (sq. ft) 1.85 2.3
No. Of Rows 2
Fins Per Inch 18 18 16
Filters
Quantity 2
Controls Integrated Microprocessor
Wireless Remote Standard
Modes Cool/Heat/Dry/Auto
Fan Mode High/Medium/Low/Auto
Emergency Mode Ye s
Defrost Method Demand Defrost
Diagnostics Yes
Air Sweep Ye s
Soft Start Ye s
Rapid Cooling/Heating Ye s
Cold Blow Prevention Ye s
Sleep Mode Ye s
24 Hour Timer Ye s
Auto Restart Ye s
FreezeProtectionOnIndoorUnit Ye s
Refrigerant Lines
Connection Type Flare
Liquid (Mix Phase) in OD 1/4”
Vapor Line in OD 3/8” 1/2”
Condensate Drain
Size in ID = 1/2” OD = 5/8”
External Finish White
