Carrier 40GVM-009 - Remove Wiring Connection Cover; Remove Conduit Connection Plate

53
REMOVAL PROCEDURE OF OUTDOOR UNIT -- 24K / 30K
Steps
Procedure
Remove the screws retaining the wiring connection
cover to the right side panel and remove cover.
1.Remove wiring connection cover and conduit connection plate
Before disassembly
Remove the screws retaining the conduit connection
plate to the right side panel and remove the plate.
Wiring
Connection Cover
Conduit Connection
Plate
