40MULA: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
11
EVAPORATOR FLANGE FABRICATION
1. Using 26 gauge sheet metal and sheet metal snips, cut flange sections 1" high for the sides and back.
2. For the front, cut a 2" high section with a 1" break to attach to the top of the front section of the cabinet.
3. Use the inner cabinet dimensions in Table 4 to cut the flange section lengths.
4. Attach flange pieces to the inside of the coil cabinet with sheet metal screws. Allow for at least 1/2” of each flange section to be installed above the coil
to allow for the supply plenum to be connected.
Table 4 — Inner Cabinet Dimensions
INNER CABINET DIMENSIONS
18K/24K 30K/36K/48K 60K
in. mm in. mm in. mm
Supply Air Opening Width 16-3/16 411 19-3/4 502 23-1/4 591
Supply Air Opening Depth 18-5/8 473 18-5/8 473 18-5/8 473
