PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
40QNQ036 WITH 388QRF036
Air Temperature
Entering Indoor
Unit ° F (° C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil ° F (° C)
17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9)
Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated
Rating Rating Rating Rating Rating Rating Rating Rating Rating Rating
55 (12.8)
620
Cap 22.09 20.14 26.45 23.49 30.71 27.95 35.71 35.71 40.41 40.41
kW 2.62 2.89 3.14 3.46 3.77
775
Cap 22.74 20.73 27.06 24.04 31.31 28.49 36.46 36.46 41.74 41.74
kW 2.48 2.73 2.94 3.21 3.49
930
Cap 23.03 21.00 27.43 24.36 31.66 28.81 37.00 37.00 42.46 42.46
kW 2.39 2.62 2.80 3.04 3.29
60 (15.6)
620
Cap 21.64 19.73 26.10 23.18 30.24 27.52 35.20 35.20 39.89 39.89
kW 2.73 3.00 3.26 3.60 3.90
775
Cap 22.22 20.26 26.69 23.71 30.89 28.11 35.99 35.99 40.98 40.98
kW 2.60 2.85 3.07 3.35 3.62
930
Cap 22.59 20.59 27.05 24.02 31.30 28.49 36.54 36.54 41.93 41.93
kW 2.51 2.74 2.93 3.18 3.43
65 (18.3)
620
Cap 21.23 19.36 25.63 22.76 29.81 27.13 34.78 34.78 39.36 39.36
kW 2.82 3.12 3.39 3.75 4.05
775
Cap 21.71 19.79 26.28 23.34 30.48 27.74 35.55 35.55 40.46 40.46
kW 2.72 2.97 3.20 3.50 3.77
930
Cap 22.11 20.16 26.65 23.67 30.87 28.10 36.07 36.07 41.17 41.17
kW 2.63 2.86 3.07 3.33 3.56
70 (21.1)
620
Cap 20.72 18.89 25.12 22.31 29.35 26.71 34.29 34.29 38.79 38.79
kW 2.92 3.26 3.52 3.88 4.20
775
Cap 21.15 19.28 25.84 22.95 30.07 27.36 35.20 35.20 39.91 39.91
kW 2.84 3.09 3.34 3.66 3.92
930
Cap 21.59 19.69 26.21 23.28 30.46 27.72 35.61 35.61 40.61 40.61
kW 2.75 2.99 3.20 3.48 3.72
75 (23.9)
620
Cap 20.18 8.66 24.63 21.87 28.83 8.66 33.81 33.81 38.21 38.21
kW 3.03 3.37 3.64 4.03 4.35
775
Cap 20.64 8.89 25.31 22.48 29.61 8.89 34.74 34.74 39.34 39.34
kW 2.94 3.23 3.47 3.81 4.08
930
Cap 20.99 19.14 25.75 22.87 30.06 27.35 35.25 35.25 40.06 40.06
kW 2.87 3.11 3.34 3.64 3.88
80 (26.7)
620
Cap 19.61 17.88 24.11 21.41 28.39 25.83 33.32 33.32 37.62 37.62
kW 3.13 3.50 3.78 4.18 4.49
775
Cap 20.12 18.34 24.74 21.97 29.14 26.52 34.26 34.26 38.75 38.75
kW 3.04 3.37 3.60 3.96 4.24
930
Cap 20.49 8.66 25.21 22.39 29.59 26.93 34.78 34.78 39.48 39.48
kW 2.97 3.25 3.47 3.79 4.04
Indicates Rating Condition (*Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor fan motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
40QNC,QNQ/38HDF,QRF
