Carrier 40QNQ User Manual

26
SOUND RATINGS
Outdoor Units
Model Number Sound Power dBa Sound Pressure dBa
3 8 H D F 0 1 8 --- --- --- 3 66 55
3 8 H D F 0 2 4 --- --- --- 3 66 55
3 8 H D F 0 3 0 --- --- --- 3 72 61
38HDF036--- --- ---3/5/6 72 61
3 8 QR F 0 1 8 --- --- --- 3 66 55
3 8 QR F 0 2 4 --- --- --- 3 66 55
3 8 QR F 0 3 0 --- --- --- 3 72 61
38QRF036--- --- ---3/5/6 72 61
Indoor Units
Model Number
High Medium Low
Sound Power
dBa
Sound Pressure
dBa
Sound Power
dBa
Sound Pressure
dBa
Sound Power
dBa
Sound Pressure
dBa
40QNC01824--- --- ---3 59 48 53 42 49 38
4 0 QN C 0 3 0 --- --- --- 3 60 49 57 46 53 5
4 0 QN C 0 3 6 --- --- --- 3 62 51 60 49 57 46
4 0 QN Q 0 1 8 --- --- --- 3 59/ 60 (Cl g/Htg) 48/49 (Cl g/Htg) 53/54 (Clg/Htg) 42/43 (Clg/Htg) 49/50 (Clg/Htg) 38/39 (Cl g/Htg)
4 0 QN Q 0 2 4 --- --- --- 3 59/ 60 (Cl g/Htg) 48/49 (Clg/Htg) 53/54 (Clg/Htg) 42/43 (Clg/Htg) 49/50 (Clg/Htg) 38/39 (Cl g/Htg)
4 0 QN Q 0 3 0 --- --- --- 3 60/61(Clg/Htg) 49/50 (Clg/Htg) 57/58 (Clg/Htg) 46/47 (Clg/Htg) 53/55 (Clg/Htg) 42/44 (Cl g/Htg)
4 0 QN Q 0 3 6 --- --- --- 3 62/ 63 (Cl g/Htg) 51/52 (Clg/Htg) 60/61 (Clg/Htg) 49/50 (Clg/Htg) 57/58 (Clg/Htg) 46/47 (Cl g/Htg)
NOTES:
1. Sou nd power ratings are tested in accordance with ARI standard 270--- --- ---95 (not listed in ARI) and ARI 350.
2. Sound pressure ratings are estimated sound pressure, 3 feet (.91 m) from the unit, based on sound power data.
WIRING
The indoor and outdoor units have their own power supply. Low voltage control wires run between the indoor and outdoor units. Two wires
are required for cooling only systems and seven wires are required for heat pumps.
ELECTRICAL DATA
38HDF/38QRF ELECTRICAL DATA
38HDF/38QRF
UNIT SIZE
V --- P H --- H z
VOLTAGE RANGE*
COMPRESSOR OUTDOOR FAN MOTOR
MIN CKT
AMPS
FUSE/
CKT
BKR
AMPS
RLA LRA FLA NEC Hp kW Out
Min Max
018 208/230---1---60 187 253 9.0 48.0 0.80 0.125 0.09 12.1 20
024 208/230---1---60 187 253 12.8 58.3 0.80 0.125 0.09 16.8 25
030 208/230---1---60 187 253 14.1 73.0 1.50 0.25 0.19 18.4 30
036
208/230---1---60 187 253 17.9 112.0 1.45 0.25 0.19 23.8 40
208/230---3---60 187 253 13.2 88.0 1.45 0.25 0.19 18.0 30
4 6 0 --- 3 --- 6 0 414 506 6.0 44.0 0.80 0.25 0.19 8.3 15
40QNC, QNQ FAN COIL ELECTRICAL DATA
UNIT SIZE V --- P H --- H z
VOLTAGE RANGE* FAN POWER
Min Max FLA
Motor Power
(Watts)
MIN CKT
AMPS
FUSE/CKT
BKR AMPS
40QNC01824 208/230---1---60 187 253 0.38 64 0.48 15
40QNC030 208/230---1---60 187 253 0.38 74 0.48 15
40QNC036 208/230---1---60 187 253 0.44 74 0.55 15
40QNQ018 208/230---1---60 187 253 0.38 64 0.48 15
40QNQ024 208/230---1---60 187 253 0.38 64 0.48 15
40QNQ030 208/230---1---60 187 253 0.38 74 0.48 15
40QNQ036 208/230---1---60 187 253 0.44 74 0.55 15
*Permissible limits of the voltage range at which unit will operate satisfactorily.
LEGEND
FLA --- F u l l L o a d A m ps
MCA --- Minimum Circuit Amps per NEC Section 430 ---24
NEC --- National Electrical Code
RLA --- RatedLoadAmps(Compressor)
NOTES:
1. In compliance with NEC requirements for multi---motor and combination
load equipment (r ef e r to NEC Articles 430 and 440), the overcurrent
protective device for the unit shall be fuse or equipped with a breaker.
2. Motor RLA values ar e established in accordance with UL (Underwriters
Laboratories) Standard 465.
®
4QNC,QNQ/38HDF,QRF
