MODEL NUMBER NOMENCLATURE
OUTDOOR UNIT
38 HDF 3---01
---
018
Air---Cooled Condenser
Unit Type
HDF --- C o o l i n g O n l y
QRF --- H e a t P u m p
Voltage
3 --- 208/230---1---60
5 --- 208/230 ---3---60*
6 --- 4 6 0 --- 3 --- 6 0 *
INDOOR UNIT
40 QNC 3---01
---
018
Fan Coil Unit
Unit Type
QNC --- C o o l i n g O n l y
QNQ --- H e a t P u m p
Voltage
3 --- 208/230---1---60
Nominal Capacity
018 --- 1 --- 1 / 2 To n s
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
Nominal Capacity
018 --- 1 --- 1 / 2 To n s
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
*Size 036 only
®
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
AHRI* CAPACITY RATINGS
Outdoor Section Indoor Section
Standard CFM
Net Cool-
ing BTUH
SEER EER
High Heat
Outdoor Indoor BTUH HSPF
3 8 H D F 0 1 8 --- --- --- 3 40QNC01824--- --- ---3 1720 645 16,600 13 11.8 N/A N/A
3 8 H D F 0 2 4 --- --- --- 3 40QNC01824--- --- ---3 1720 645 22,000 13 11.3 N/A N/A
3 8 H D F 0 3 0 --- --- --- 3 3 0 Q N C 0 3 0 --- --- --- 3 1720 730 27,000 13 11.7 N/A N/A
3 8 H D F 0 3 6 --- --- --- 3 4 0 Q N C 0 3 6 --- --- --- 3 3900 900 34,200 13 11.3 N/A N/A
3 8 H D F 0 3 6 --- --- --- 5 4 0 Q N C 0 3 6 --- --- --- 3 3900 900 34,200 13 11.3 N/A N/A
3 8 H D F 0 3 6 --- --- --- 6 4 0 Q N C 0 3 6 --- --- --- 3 3900 900 34,200 13 11.3 N/A N/A
3 8 QR F 0 1 8 --- --- --- 3 4 0 QN Q 0 1 8 --- --- --- 3 1720 645 17,400 13 11.3 17,000 7.7
3 8 QR F 0 2 4 --- --- --- 3 4 0 QN Q 0 2 4 --- --- --- 3 1720 645 22,800 13 11.5 22,000 7.7
3 8 QR F 0 3 0 --- --- --- 3 3 0 QN Q 0 3 0 --- --- --- 3 3900 730 27,000 13 11.7 28,200 7.7
3 8 QR F 0 3 6 --- --- --- 3 4 0 QN Q 0 3 6 --- --- --- 3 3900 900 32,600 13 10.9 35,600 7.7
3 8 QR F 0 3 6 --- --- --- 5 4 0 QN Q 0 3 6 --- --- --- 3 3900 900 32,600 13 10.9 35,600 7.7
3 8 QR F 0 3 6 --- --- --- 6 4 0 QN Q 0 3 6 --- --- --- 3 3900 900 32,600 13 10.9 35,600 7.7
*Air Conditioning, Heating & Refrigeration Institute
Legend
HSPF --- Heating Seasonal Performance Factor
SEER --- Seasonal E n ergy Efficiency Ratio
NOTES:
1. Ratings are net values reflecting the effects of circulating fan heat. Ratings are based on: Cooling Standard: 80_F (26.67_C) db, 67_F (19.44_C) wb air
entering indoor unit and 95_F(35_C) db air entering outdoor unit. High Temperature Heating Standard: 70_F (21.11_C) db air entering indoor unit and 47_F
(8.33_C) db, 43_F (6.11_C) wb air entering outdoor unit.
2. Ratings are based on 25 ft. (7.62 m) of interconnecting refrigerant lines.
3. Al l system ratings are based on fan coil units operating at high fan speed. Con sult Physical Data tables for airflows at all available fan speeds.
40QNC,QNQ/38HDF,QRF
