Carrier 40QNQ User Manual

12
PERFORMANCE DATA
COOLING CAPACITIES
38HDF018 WITH 40QNC01824
Te m p ° F ( ° C )
Air Entering
Condenser
(Edb)
Air Entering Evaporator --- Cfm/BF
460/0.04 525/0.04 645/0.05
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 15.9 16.7 18.0 18.5 16.0 17.1 18.1 18.7 16.4 17.5 18.3 18.7
SHG 14.5 12.3 10.9 9.2 14.7 12.9 10.9 9.4 15.1 13.2 11.3 9.4
TC 15.7 16.5 17.8 18.3 15.8 16.9 17.9 18.5 16.2 17.3 18.1 18.5
kW 0.88 0.89 0.89 0.89 0.89 0.89 0.90 0.89 0.89 0.89 0.89 0.89
CMP 0.70 0.70 0.70 0.70 0.70 0.70 0.71 0.70 0.70 0.70 0.70 0.70
LDB 48.8 53.9 57.2 61.2 51.0 54.8 59.0 62.3 53.4 57.0 60.7 64.2
LWB 41.8 47.6 53.2 59.4 43.1 48.6 54.3 60.4 44.4 50.0 55.8 61.9
65
(18.3)
TCG 15.7 16.6 17.9 18.9 16.0 16.9 18.1 18.9 16.3 17.2 18.4 19.0
SHG 14.8 12.5 11.0 9.2 15.0 12.9 11.1 9.3 15.3 13.4 11.5 9.5
TC 15.5 16.4 17.7 18.7 15.8 16.7 17.9 18.7 16.1 17.0 18.2 18.8
kW 1.00 1.00 1.00 1.01 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
CMP 0.81 0.82 0.81 0.82 0.81 0.82 0.82 0.82 0.81 0.81 0.81 0.82
LDB 48.1 53.5 57.0 61.1 50.4 54.8 58.6 62.4 53.1 56.8 60.2 64.1
LWB 41.9 47.7 53.3 59.1 43.0 48.7 54.3 60.3 44.5 50.2 55.7 61.7
75
(23.9)
TCG 15.2 16.4 17.5 18.8 15.7 16.5 17.8 19.0 16.1 16.9 18.1 19.2
SHG 14.6 12.7 10.8 9.2 15.2 12.9 11.1 9.3 16.1 13.4 11.4 9.5
TC 15.0 16.2 17.3 18.6 15.5 16.3 17.6 18.8 15.9 16.7 17.9 19.0
kW 1.12 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13
CMP 0.93 0.94 0.94 0.94 0.94 0.94 0.94 0.95 0.94 0.94 0.94 0.95
LDB 48.5 52.9 57.5 61.1 49.9 54.8 58.7 62.5 51.6 56.6 60.4 64.1
LWB 42.5 47.9 53.6 59.2 43.4 49.1 54.6 60.2 44.7 50.4 55.9 61.6
85
(29.4)
TCG 14.2 15.8 17.1 18.3 15.0 16.1 17.3 18.6 15.7 16.3 17.6 18.9
SHG 14.2 12.7 10.7 9.0 14.9 13.1 10.9 9.2 15.7 13.4 11.4 9.4
TC 14.0 15.6 16.8 18.1 14.7 15.9 17.1 18.4 15.5 16.1 17.4 18.7
kW 1.24 1.26 1.27 1.27 1.25 1.27 1.27 1.27 1.27 1.27 1.27 1.27
CMP 1.06 1.08 1.08 1.09 1.07 1.08 1.08 1.09 1.08 1.08 1.08 1.09
LDB 49.4 53.0 57.7 61.6 50.4 54.3 58.9 62.6 52.4 56.6 60.5 64.2
LWB 43.6 48.5 54.0 59.6 44.1 49.5 55.0 60.5 45.1 50.8 56.2 61.8
95
(35.0)
TCG 13.2 14.7 16.6 17.8 13.5 14.6 16.8 18.1 15.0 15.6 16.8 18.4
SHG 12.3 12.1 10.7 8.7 13.5 11.6 10.9 9.1 15.0 13.5 11.0 9.3
TC 13.0 14.5 16.4 17.6 13.3 14.4 16.6 17.9 14.8 15.4 16.6 18.2
kW 1.38 1.40 1.42 1.43 1.38 1.40 1.42 1.43 1.41 1.41 1.41 1.43
CMP 1.19 1.22 1.24 1.24 1.20 1.21 1.24 1.24 1.22 1.23 1.22 1.24
LDB 53.7 54.3 57.5 62.2 53.2 57.3 59.0 62.9 53.5 56.5 60.7 64.4
LWB 44.7 49.6 54.4 60.0 45.5 50.8 55.4 60.9 45.6 51.4 56.7 62.1
105
(40.6)
TCG 12.6 14.0 15.7 17.1 13.1 14.2 16.0 17.3 13.5 14.5 16.3 17.6
SHG 12.6 12.0 10.4 8.5 13.1 12.5 10.7 8.7 13.5 13.2 11.2 9.1
TC 12.4 13.8 15.5 16.9 12.9 14.0 15.8 17.1 13.3 14.3 16.1 17.4
kW 1.53 1.56 1.58 1.59 1.53 1.56 1.59 1.59 1.54 1.57 1.59 1.60
CMP 1.34 1.37 1.40 1.41 1.35 1.38 1.40 1.41 1.36 1.38 1.41 1.41
LDB 52.9 54.4 58.2 62.6 54.2 55.5 59.3 63.7 56.3 57.0 60.7 64.8
LWB 45.3 50.3 55.1 60.5 45.9 51.1 56.0 61.4 46.9 52.2 57.1 62.5
115
(46.1)
TCG 11.8 12.5 14.1 16.3 12.3 12.8 14.9 16.5 12.9 13.3 15.2 16.7
SHG 11.8 10.7 9.2 8.2 12.3 11.0 10.3 8.4 12.9 11.8 10.9 8.7
TC 11.6 12.3 13.9 16.1 12.1 12.5 14.7 16.2 12.7 13.1 15.0 16.5
kW 1.69 1.70 1.74 1.77 1.70 1.71 1.76 1.78 1.71 1.72 1.76 1.78
CMP 1.51 1.52 1.55 1.59 1.51 1.52 1.57 1.59 1.52 1.53 1.57 1.59
LDB 54.7 57.4 60.7 63.2 55.6 58.4 60.1 64.1 57.4 59.4 61.3 65.5
LWB 46.2 51.6 56.5 61.1 46.6 52.4 56.8 62.0 47.4 53.1 57.9 63.1
125
(51.7)
TCG 11.1 11.5 13.4 15.3 11.4 11.8 13.3 15.5 11.9 12.1 14.0 15.7
SHG 11.1 10.4 9.6 8.0 11.4 10.8 9.2 8.1 11.9 11.3 10.4 8.4
TC 10.9 11.3 13.2 15.1 11.2 11.6 13.1 15.3 11.7 11.9 13.8 15.5
kW 1.87 1.88 1.93 1.97 1.88 1.88 1.92 1.97 1.88 1.89 1.94 1.97
CMP 1.69 1.69 1.74 1.78 1.69 1.70 1.73 1.78 1.70 1.70 1.75 1.79
LDB 56.3 57.9 59.9 63.7 57.5 58.9 62.3 64.7 59.2 60.4 62.1 65.9
LWB 46.9 52.5 57.1 61.9 47.5 53.2 58.0 62.6 48.2 54.0 58.7 63.7
Rating condition
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving Dry Bulb
L W B --- L e a v i n g W e t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG --- Gross Cooling Capacity ( 1000 Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QNC,QNQ/38HDF,QRF
