13
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDF024 WITH 40QNC1824
Te m p ° F ( ° C )
Air Entering
Condenser
(Edb)
Air Entering Evaporator --- Cfm/BF
460/0.04 525/0.04 645/0.05
A i r E n t e r i n g E v a p o r a t o r --- E w b ° F ( ° C )
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 20.1 21.6 23.0 23.6 20.5 22.0 23.1 23.8 21.1 22.5 23.4 23.8
SHG 17.5 15.5 13.7 11.6 18.0 16.0 13.8 11.7 18.9 16.6 14.1 11.8
TC 19.9 21.4 22.8 23.4 20.3 21.8 22.9 23.6 20.9 22.3 23.2 23.6
kW 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10
CMP 0.91 0.91 0.91 0.91 0.91 0.91 0.91 0.92 0.91 0.91 0.91 0.92
LDB 48.3 52.3 55.9 59.9 50.0 53.7 57.6 61.4 52.1 55.7 59.7 63.4
LWB 40.6 46.2 51.9 58.4 41.8 47.3 53.2 59.5 43.2 48.8 54.8 61.1
65
(18.3)
TCG 20.3 21.5 22.8 24.1 20.9 21.8 23.4 24.3 21.2 22.3 23.7 24.4
SHG 18.5 15.8 13.6 11.7 19.3 16.1 14.0 11.8 19.6 16.7 14.4 12.0
TC 20.1 21.3 22.6 23.9 20.7 21.6 23.1 24.1 21.0 22.1 23.5 24.2
kW 1.25 1.25 1.26 1.26 1.25 1.26 1.26 1.26 1.25 1.26 1.26 1.26
CMP 1.07 1.07 1.07 1.07 1.07 1.07 1.07 1.07 1.07 1.07 1.07 1.07
LDB 46.4 51.7 56.1 59.7 47.7 53.5 57.2 61.2 50.9 55.6 59.3 63.1
LWB 40.4 46.2 52.1 58.0 41.5 47.5 53.1 59.2 43.2 49.0 54.6 60.7
75
(23.9)
TCG 18.5 20.3 22.7 24.3 19.0 21.6 23.0 24.5 20.6 21.9 23.5 24.7
SHG 16.4 14.8 13.6 11.7 16.9 16.5 13.9 11.9 19.5 16.9 14.5 12.1
TC 18.3 20.1 22.5 24.0 18.8 21.4 22.8 24.3 20.3 21.7 23.3 24.5
kW 1.4 1.41 1.43 1.43 1.40 1.43 1.43 1.43 1.42 1.43 1.43 1.43
CMP 1.2 1.23 1.25 1.25 1.21 1.24 1.24 1.25 1.23 1.24 1.25 1.25
LDB 50.4 53.6 56.0 59.7 51.9 52.9 57.4 61.2 51.0 55.2 59.2 63.0
LWB 42.4 47.2 52.2 57.9 43.1 47.6 53.3 59.1 43.7 49.2 54.7 60.6
85
(29.4)
TCG 18.4 20.2 22.1 23.8 18.9 20.9 22.5 24.1 19.3 21.6 23.0 24.6
SHG 17.6 14.8 13.4 11.4 18.2 16.4 13.9 11.6 17.4 16.9 14.4 12.0
TC 18.2 20.0 21.9 23.6 18.7 20.7 22.3 23.9 19.1 21.4 22.8 24.4
kW 1.6 1.6 1.62 1.63 1.57 1.60 1.62 1.63 1.58 1.6 1.62 1.63
CMP 1.4 1.4 1.44 1.44 1.39 1.41 1.44 1.44 1.39 1.4 1.44 1.44
LDB 48.0 53.6 56.3 60.3 49.7 53.0 57.5 61.5 45.9 55.3 59.3 63.0
LWB 42.4 47.4 52.6 58.2 43.1 48.2 53.6 59.3 43.7 49.6 55.1 60.7
95
(35.0)
TCG 16.9 19.8 21.6 23.2 17.4 19.1 21.9 23.4 18.5 20.7 22.2 23.9
SHG 15.8 15.0 13.5 11.2 16.3 14.6 13.7 11.4 17.8 16.5 14.2 11.8
TC 16.7 19.6 21.4 23.0 17.2 18.9 21.7 23.2 18.3 20.5 22.0 23.7
kW 1.74 1.8 1.83 1.83 1.75 1.78 1.83 1.84 1.8 1.81 1.83 1.84
CMP 1.56 1.6 1.64 1.65 1.56 1.59 1.64 1.65 1.6 1.62 1.64 1.65
LDB 51.4 53.1 56.1 60.7 53.0 56.0 57.7 61.9 53.8 55.8 59.5 63.4
LWB 43.6 47.8 52.9 58.7 44.0 49.5 54.1 59.7 44.7 50.7 55.5 61.0
105
(40.6)
TCG 16.7 19.9 20.6 22.2 16.8 17.6 21.0 22.6 17.3 18.6 21.4 17.6
SHG 15.0 13.5 13.1 10.8 15.6 15.1 13.5 11.1 15.8 14.9 14.0 9.1
TC 16.5 19.7 20.4 22.0 16.6 17.4 20.8 22.4 17.1 18.4 21.2 17.4
kW 1.95 2.0 2.04 2.06 1.95 2.00 2.05 2.06 2.0 1.98 2.06 1.60
CMP 1.76 1.8 1.86 1.87 1.77 1.81 1.87 1.87 1.8 1.79 1.87 1.41
LDB 52.9 56.0 56.9 61.4 54.1 55.0 58.1 62.4 54.8 58.2 59.7 64.8
LWB 43.8 47.9 53.7 59.3 44.8 50.6 54.7 60.2 45.6 51.4 56.0 62.5
115
(46.1)
TCG 15.3 16.5 19.2 21.3 15.7 16.8 19.7 21.6 16.3 17.5 20.1 21.9
SHG 15.3 13.5 12.6 10.5 15.7 13.9 13.0 10.7 16.3 14.3 13.6 11.0
TC 15.1 16.3 19.0 21.1 15.5 16.6 19.5 21.4 16.1 17.3 19.9 21.7
kW 2.15 2.17 2.25 2.30 2.16 2.18 2.27 2.30 2.17 2.2 2.28 2.30
CMP 1.97 1.99 2.06 2.12 1.97 1.99 2.09 2.12 1.99 2.0 2.10 2.12
LDB 52.3 55.9 57.7 61.9 53.9 57.2 59.0 63.1 55.8 59.0 60.4 64.4
LWB 45.0 50.4 54.8 59.9 45.8 51.2 55.5 60.8 46.7 52.1 56.7 62.0
125
(51.7)
TCG 14.4 15.3 17.9 20.2 14.8 15.6 18.2 20.4 15.4 15.9 18.7 20.8
SHG 14.4 13.1 12.1 10.1 14.8 13.5 12.5 10.3 15.4 14.1 13.0 10.6
TC 14.2 15.1 17.7 20.0 14.6 15.4 18.0 20.2 15.2 15.7 18.5 20.6
kW 2.38 2.40 2.48 2.56 2.39 2.40 2.49 2.56 2.40 2.41 2.52 2.56
CMP 2.19 2.21 2.29 2.37 2.20 2.22 2.30 2.38 2.22 2.23 2.33 2.37
LDB 53.9 56.6 58.7 62.6 55.3 57.7 59.7 63.7 57.2 59.3 61.3 65.0
LWB 45.8 51.3 55.7 60.6 46.4 52.0 56.5 61.5 47.4 53.0 57.5 62.6
Rating condition
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving Dry Bulb
L W B --- L e a v i n g W e t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG
---
Gross
Cooling
Capacity
(1000
Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QNC,QNQ/38HDF,QRF
