Carrier 40QNQ User Manual

14
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDF030 WITH 40QNC030
Te m p ° F ( ° C )
Air Entering
Condenser
(Edb)
AirEnteringEvaporator-Cfm/BF
530/0.04 630/0.04 730/0.05
AirEnteringEvaporator-Ewb°F(°C)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 26.6 27.8 28.6 29.6 27.2 28.0 28.9 29.9 27.6 28.5 29.3 30.4
SHG 26.0 21.8 17.6 13.8 27.0 22.1 18.1 14.2 27.5 22.6 18.4 14.7
TC 26.5 27.6 28.5 29.4 27.0 27.8 28.7 29.7 27.3 28.2 29.0 30.1
kW 1.44 1.45 1.46 1.46 1.44 1.45 1.46 1.46 1.45 1.45 1.46 1.46
CMP 1.25 1.25 1.26 1.26 1.25 1.25 1.26 1.27 1.25 1.25 1.26 1.27
LDB 41.8 48.4 54.8 60.7 44.3 51.2 56.8 62.2 48.5 54.4 59.6 64.1
LWB 39.2 45.4 51.8 58.2 40.9 47.2 53.4 59.6 43.2 49.2 55.3 61.3
65
(18.3)
TCG 26.4 27.6 28.7 29.8 27.0 28.0 29.1 30.1 27.7 28.5 29.5 30.5
SHG 25.7 22.3 18.1 14.2 26.2 23.0 18.4 14.6 27.5 23.6 19.1 15.0
TC 26.2 27.4 28.6 29.6 26.8 27.8 28.8 29.9 27.4 28.3 29.2 30.3
kW 1.63 1.64 1.65 1.65 1.63 1.64 1.65 1.65 1.64 1.64 1.65 1.65
CMP 1.44 1.44 1.45 1.45 1.44 1.44 1.45 1.46 1.44 1.45 1.46 1.46
LDB 42.3 47.5 54.2 60.1 45.4 49.9 56.3 61.7 48.5 53.3 58.8 63.7
LWB 39.4 45.5 51.8 58.1 41.0 47.2 53.3 59.5 43.1 49.2 55.2 61.2
75
(23.9)
TCG 25.5 26.9 28.2 29.3 26.3 27.3 28.5 29.6 27.1 27.8 28.9 30.0
SHG 24.7 22.3 18.1 14.1 26.3 23.1 18.5 14.5 27.1 24.2 19.0 15.0
TC 25.4 26.8 28.0 29.1 26.1 27.1 28.2 29.3 26.9 27.6 28.6 29.7
kW 1.83 1.85 1.86 1.86 1.84 1.85 1.85 1.86 1.85 1.85 1.86 1.87
CMP 1.63 1.65 1.66 1.67 1.64 1.65 1.66 1.67 1.65 1.66 1.66 1.67
LDB 43.8 47.6 54.0 60.3 45.3 49.7 56.3 61.7 49.0 52.6 58.9 63.7
LWB 40.1 46.0 52.1 58.3 41.5 47.6 53.7 59.8 43.4 49.5 55.5 61.4
85
(29.4)
TCG 24.2 26.1 27.7 28.7 25.2 26.6 28.0 28.9 26.5 27.1 28.3 29.3
SHG 24.2 22.0 18.3 14.0 25.2 23.1 18.7 14.5 26.5 24.5 19.4 15.0
TC 24.1 25.9 27.6 28.6 25.0 26.4 27.8 28.7 26.2 26.8 28.0 29.1
kW 2.04 2.07 2.09 2.09 2.06 2.08 2.09 2.10 2.08 2.08 2.09 2.10
CMP 1.84 1.88 1.89 1.90 1.86 1.88 1.89 1.90 1.88 1.88 1.89 1.90
LDB 44.4 47.9 53.7 60.4 46.7 49.8 55.8 61.8 49.7 52.3 58.4 63.7
LWB 41.1 46.6 52.4 58.6 42.2 48.0 53.9 60.1 43.8 49.9 55.8 61.7
95
(35.0)
TCG 23.1 24.7 27.0 28.1 24.1 25.3 27.2 28.3 25.4 26.0 27.3 28.6
SHG 23.1 21.1 18.2 14.0 24.1 22.5 18.8 14.4 25.4 24.6 19.4 14.9
TC 22.9 24.5 26.8 27.9 23.9 25.1 27.0 28.1 25.2 25.7 27.0 28.3
kW 2.27 2.30 2.33 2.34 2.29 2.31 2.34 2.35 2.32 2.32 2.31 2.35
CMP 2.07 2.10 2.14 2.15 2.10 2.12 2.14 2.15 2.12 2.13 2.11 2.15
LDB 46.1 49.2 53.9 60.4 48.2 50.6 55.7 61.9 51.0 52.1 58.0 63.8
LWB 42.0 47.5 52.8 59.0 43.0 48.8 54.3 60.4 44.4 50.5 56.1 62.0
105
(40.6)
TCG 22.0 23.1 25.8 27.2 22.8 23.6 26.2 27.4 24.1 24.4 26.5 17.7
SHG 22.0 20.2 17.9 13.9 22.8 21.6 18.7 14.2 24.1 23.5 19.5 9.2
TC 21.9 23.0 25.6 27.0 22.6 23.4 26.0 27.2 23.9 24.1 26.2 17.4
kW 2.52 2.54 2.60 2.61 2.54 2.55 2.60 2.62 2.57 2.57 2.60 1.60
CMP 2.32 2.34 2.40 2.42 2.34 2.36 2.40 2.42 2.38 2.38 2.41 1.40
LDB 47.7 50.6 54.3 60.5 49.9 51.7 55.9 62.1 52.4 53.3 58.2 64.8
LWB 42.7 48.6 53.5 59.5 43.8 49.8 54.9 60.8 45.1 51.2 56.5 62.5
115
(46.1)
TCG 20.8 21.5 24.0 25.9 21.5 22.0 24.6 26.2 22.7 22.9 25.1 26.4
SHG 20.8 19.6 17.0 13.6 21.5 20.6 18.1 14.0 22.7 22.4 19.2 14.5
TC 20.7 21.4 23.9 25.8 21.3 21.7 24.4 25.9 22.4 22.6 24.9 26.1
kW 2.78 2.80 2.86 2.90 2.80 2.81 2.88 2.90 2.84 2.84 2.88 2.90
CMP 2.59 2.60 2.67 2.70 2.61 2.62 2.68 2.70 2.64 2.64 2.69 2.71
LDB 49.5 51.5 55.6 60.9 51.7 53.1 56.7 62.4 54.1 54.7 58.5 64.2
LWB 43.6 49.6 54.6 60.1 44.7 50.8 55.7 61.3 45.9 52.0 57.1 62.8
125
(51.7)
TCG 19.3 19.8 22.1 24.2 20.0 20.6 22.6 24.5 21.2 21.4 23.3 24.7
SHG 19.3 18.8 16.1 13.0 20.0 20.0 17.2 13.4 21.2 20.7 18.6 14.0
TC 19.1 19.7 22.0 24.0 19.8 20.4 22.4 24.3 20.9 21.2 23.0 24.4
kW 3.07 3.07 3.14 3.19 3.08 3.09 3.16 3.19 3.12 3.12 3.18 3.19
CMP 2.87 2.88 2.94 2.99 2.88 2.90 2.96 3.00 2.93 2.93 2.98 3.00
LDB 51.7 52.6 56.9 61.8 53.7 53.8 57.8 63.1 55.8 56.6 59.1 64.8
LWB 44.7 50.7 55.7 61.0 45.7 51.5 56.7 62.1 46.7 52.7 57.9 63.5
Rating condition
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving Dry Bulb
L W B --- L e a v i n g W e t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG
---
Gross
Cooling
Capacity
(1000
Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QNC,QNQ/38HDF,QRF
