Carrier 40QNQ User Manual

15
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38HDF036 WITH 40QNC036
Te m p ° F ( ° C )
Air Entering
Condenser
(Edb)
AirEnteringEvaporator-Cfm/BF
600/0.04 750/0.04 900/0.05
AirEnteringEvaporator-Ewb°F(°C)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
57
(13.9)
62
(16.7)
67
(19.4)
72
(22.2)
55
(12.8)
TCG 33.6 34.5 35.2 36.3 33.8 35.0 35.7 36.6 34.2 35.4 36.0 37.0
SHG 31.3 26.1 21.2 16.5 31.6 26.4 22.0 17.1 32.2 26.9 22.0 17.6
TC 33.4 34.3 35.0 36.1 33.5 34.7 35.5 36.4 33.9 35.1 35.6 36.7
kW 1.96 1.97 1.98 1.99 1.96 1.97 1.98 1.99 1.97 1.97 1.98 1.99
CMP 1.64 1.65 1.65 1.66 1.64 1.65 1.65 1.66 1.64 1.65 1.66 1.66
LDB 40.0 47.0 53.7 59.9 43.2 49.6 55.0 61.0 46.8 52.6 58.0 62.8
LWB 37.2 43.8 50.5 57.1 39.0 45.4 52.0 58.4 41.2 47.4 53.9 60.1
65
(18.3)
TCG 32.7 34.9 36.3 37.3 33.6 35.3 36.6 37.4 34.5 35.9 36.8 37.8
SHG 31.2 26.9 22.2 17.0 33.2 27.6 22.5 17.6 34.5 28.5 23.1 18.1
TC 32.5 34.7 36.1 37.1 33.3 35.0 36.4 37.1 34.2 35.6 36.5 37.5
kW 2.19 2.21 2.22 2.22 2.20 2.21 2.22 2.23 2.21 2.21 2.22 2.23
CMP 1.87 1.89 1.89 1.89 1.88 1.89 1.89 1.90 1.88 1.89 1.89 1.90
LDB 40.1 45.9 52.4 59.4 41.2 48.2 54.4 60.5 44.4 50.9 56.8 62.2
LWB 37.8 43.5 49.9 56.6 39.2 45.2 51.5 58.1 41.1 47.2 53.5 59.8
75
(23.9)
TCG 31.6 34.7 36.5 37.6 32.5 35.2 36.7 37.9 33.9 35.7 37.2 38.2
SHG 30.2 27.4 22.9 17.3 31.6 28.0 23.2 18.0 33.9 29.2 23.7 18.7
TC 31.4 34.5 36.3 37.4 32.3 34.9 36.5 37.6 33.6 35.4 36.9 37.9
kW 2.44 2.47 2.48 2.49 2.45 2.48 2.49 2.49 2.47 2.48 2.49 2.50
CMP 2.11 2.15 2.16 2.17 2.13 2.15 2.16 2.17 2.15 2.15 2.17 2.17
LDB 41.5 45.4 51.4 58.9 43.1 47.6 53.6 60.0 45.0 50.2 56.2 61.6
LWB 38.6 43.6 49.8 56.4 39.8 45.3 51.4 57.9 41.4 47.3 53.3 59.6
85
(29.4)
TCG 30.3 33.3 36.0 37.3 31.5 34.1 36.2 37.5 33.1 34.9 36.7 37.9
SHG 29.3 26.7 22.7 17.9 30.4 27.9 23.3 18.1 31.7 29.3 24.0 18.7
TC 30.1 33.1 35.8 37.1 31.2 33.9 36.0 37.3 32.7 34.6 36.4 37.6
kW 2.71 2.74 2.78 2.79 2.73 2.76 2.78 2.79 2.75 2.77 2.79 2.79
CMP 2.38 2.41 2.45 2.47 2.40 2.43 2.46 2.46 2.42 2.45 2.46 2.47
LDB 42.6 46.2 51.7 58.2 44.5 47.8 53.5 59.9 47.3 50.0 55.9 61.6
LWB 39.4 44.5 50.1 56.5 40.5 45.8 51.7 58.0 41.8 47.6 53.5 59.7
95
(35.0)
TCG 29.2 31.7 35.2 36.9 30.4 32.5 35.6 37.0 31.3 33.4 36.0 37.4
SHG 28.2 25.6 22.7 18.1 29.1 26.9 23.2 18.3 31.3 28.6 24.0 18.7
TC 29.0 31.5 35.0 36.7 30.1 32.2 35.4 36.7 31.0 33.1 35.7 37.0
kW 3.00 3.04 3.10 3.12 3.03 3.06 3.10 3.12 3.05 3.08 3.11 3.12
CMP 2.68 2.71 2.78 2.79 2.70 2.73 2.78 2.79 2.72 2.75 2.78 2.79
LDB 43.9 47.7 51.7 57.9 46.1 48.9 53.6 59.6 47.7 50.7 55.8 61.7
LWB 40.2 45.5 50.5 56.8 41.1 46.7 52.0 58.2 42.7 48.3 53.8 59.9
105
(40.6)
TCG 28.1 30.1 33.5 35.9 28.4 30.7 34.2 36.3 29.9 31.5 35.1 17.8
SHG 27.3 24.4 21.8 17.8 28.4 25.8 22.8 18.2 29.9 27.5 24.0 9.2
TC 27.9 29.9 33.3 35.7 28.2 30.5 34.0 36.1 29.5 31.2 34.7 17.4
kW 3.32 3.36 3.43 3.47 3.34 3.37 3.45 3.47 3.37 3.39 3.46 1.60
CMP 3.00 3.03 3.10 3.14 3.01 3.05 3.12 3.15 3.04 3.07 3.14 1.27
LDB 45.2 49.1 52.8 58.3 46.8 50.1 54.0 59.7 49.2 51.9 55.8 61.6
LWB 40.9 46.5 51.5 57.2 42.3 47.7 52.7 58.5 43.5 49.2 54.2 60.2
115
(46.1)
TCG 26.4 28.4 31.4 34.8 27.0 28.8 32.1 35.1 28.3 29.6 33.0 35.5
SHG 26.4 23.5 20.7 17.5 27.0 24.5 21.8 17.9 28.3 26.4 23.2 18.5
TC 26.2 28.2 31.2 34.6 26.7 28.5 31.8 34.9 28.0 29.2 32.7 35.1
kW 3.67 3.71 3.78 3.85 3.69 3.72 3.79 3.86 3.72 3.74 3.82 3.86
CMP 3.35 3.38 3.45 3.53 3.36 3.39 3.47 3.53 3.39 3.41 3.49 3.54
LDB 46.3 50.2 54.2 58.6 48.5 51.7 55.1 60.1 50.8 53.0 56.6 61.8
LWB 42.1 47.5 52.6 57.8 43.2 48.7 53.7 59.0 44.3 50.1 55.1 60.6
125
(51.7)
TCG 24.4 26.2 29.2 33.0 25.5 26.5 29.8 33.4 26.4 27.1 30.5 33.8
SHG 24.4 22.7 19.6 16.9 25.5 23.5 20.6 17.3 26.4 25.1 22.1 17.9
TC 24.2 26.0 29.0 32.8 25.2 26.3 29.5 33.1 26.1 26.8 30.2 33.5
kW 4.07 4.08 4.16 4.27 4.07 4.09 4.17 4.27 4.09 4.11 4.19 4.28
CMP 3.74 3.76 3.83 3.95 3.75 3.76 3.85 3.94 3.77 3.78 3.87 3.95
LDB 48.8 51.3 55.5 59.3 50.3 52.8 56.5 60.7 52.8 54.4 57.7 62.3
LWB 43.3 48.8 53.8 58.6 44.0 49.9 54.8 59.8 45.3 51.2 56.1 61.2
Rating condition
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving Dry Bulb
L W B --- L e a v i n g W e t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG
---
Gross
Cooling
Capacity
(1000
Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x ( 1 --- BF) x (edb --- 80).
40QNC,QNQ/38HDF,QRF
