PHYSICAL DATA (CONT.) -- OUTDOOR UNIT 38QRF
Outdoor Unit 38QRF 018 024 030 036 036 036
System V oltage 208/230---1---60 208/230---1---60 208/230---1---60 208/230---1---60 208/230---3---60 4 6 0 --- 3 --- 6 0
Nominal Capacity (Btuh) 18000 24000 30000 36000 36000 36000
Operating Weight lb(kg) 166 (75.3) 176 (79.8) 187 (84.8) 232 (105.2) 232 (105.2) 232 (105.2)
Refrigerant Type R--- 410A
Unit Factory Charge lb(kg) 5.5 (2.5) 6.8 (3.1) 10.7 (4.9) 10.0 (4.5) 10.0 (4.5) 10.0 ( 4.5)
System Charge (25 ft line)
lb(kg)
6.3 (2.9) 7.3 (3.3) 10.7 (4.9) 10.0 (4.5) 10.0 (4.5) 10.0 (4.5)
Additional Charge lb(kg) .8 (.36) .5 (.23) 0.0 0.0 0.0 0.0
Metering Device Accurator at Outdoor Unit
Cooling Piston 49 55 63 70 70 70
Heating Piston 45 49 53 63 63 63
Compressor
Type Scroll
Model ZP16K5E---PFV ZP21K5E ---PFV ZP25K5E---PFV ZP34K5E---PFV ZP34KE---TF5 ZP34KE---TFD
O i l C h a r g e ( PO E --- o z ) 25 25 25 42 42 42
Crankcase Heater (watts) NA NA 40 NA NA NA
Outdoor Fan
Rpm/CFM 840/1720 840/1720 850/ 3900 850/3900 850/3900 850/ 3900
Diameter (in) .. No. of Blades
18…3 18…3 18…3 24…3 24…3 24…3
Motor HP 1/8 1/8 1/4 1/4 1/4 1/4
Outdoor Coil
Face Area (sq. ft) 5.82 7.27 12.1 12.1 12.1 12.1
No. Rows 2 3 2 2 2 2
Fins per inch 20 20 20 20 20 20
Circuits 3 3 6 6 6 6
High Pressure Switch
C u t --- I n ( p s i g ) 420±25 420±25 420±25 420±25 420±25 420±25
C u t --- O u t ( p si g ) 650±10 650±10 650±10 650±10 650±10 650±10
Low Pressure Switch
C u t --- I n ( p s i g ) 45±25 45±25 45±25 45±25 45±25 45±25
C u t --- O u t ( p si g ) 20±5
Fusible Plug ° F (° C) 210 (99)
Refrigerant Lines
Connection Type M ix e d P h a s e --- F l a r e / S u c t io n --- S w e a t
Suction/Vapor (in) OD 5/8 3/4
Mixed Phase * (in) OD 3/8
Maximum Len gth** ft ( m) 200 (61)
Max Lift (Fan Coil Above) ft
(m)
65 (20)
Max Drop (Fan Coil Below) f t
(m)
200 (61)
Controls
Control Voltage 24 vac
External Finish Gray
* Mixed phase line n eeds to be insulated
** Refer to Duct --- Free Split System Long Line Guide for additional information. Long Line accessories required byond 80 ft (24.4 m).
40QNC,QNQ/38HDF,QRF
