116
PANEL NO. 2 WITHOUT DOOR
61.1
A
PANEL NO. 1 FOR 42SU
52.5
A
PANEL NO. 1 FOR 42SM
60.5
A
RETURN-AIR WALL PANELS FOR FURRED-IN UNITS — PANELS WITH NO FRAME
PANEL DIMENSIONS (in.)
NOTE: Dimensions in inches.
PANEL NO. UNIT UNIT SIZE A
1
42SG,SJ,
SU
03, 04 15.5
06, 08 19.5
10, 12 23.5
42SM 14,16,20 29.5
2 42SG,SJ
03, 04 15.5
06, 08 19.5
10, 12 23.5
3 42SG,SJ
03, 04 15.2
06, 08 19.2
10, 12 23.2
PANEL NO. 1
55.5
A
a42-4167
PANEL NO. 2
61.1
A
a42-4169
PANEL NO. 3
55.3
A
A42-4173
A42-4272
A42-4274
A42-4275
Accessory dimensions (cont)
42S Series Units
