58
AIR DELIVERY FAN CURVES
42CE SERIES — 02 UNIT SIZE
42CE SERIES — 03 UNIT SIZE
SCFM
ECM Operating Range:
PSC Motor Fan Curve: 3-Row - 5-Row
4-Row
0
0.05
0.10
0.15
0.20
0.25
0.30
0.35
0.40
0.45
0.50
0 50 100 150 200 250 300 350
ESP (in. wg)
Low
Med
High
0 50 100 150 200 250 300 350 400 450
SCFM
ECM Operating Range:
PSC Motor Fan Curve: 3-Row
-
5-Row
4-Row
0
0.05
0.10
0.15
0.20
0.25
0.30
0.35
0.40
0.45
0.50
ESP (in. wg)
Low
Med
High
LEGEND
ECM — Electronically Commutated Motor
ESP — External Static Pressure
PSC — Permanent Split Capacitor
SCFM — Square Cubic Feet per Minute
Performance data (cont)
42C Series Units
