VSEBINA
SI-2
1. PRIPRAVA NA NAMESTITEV ............................................................................................. 3
2. PREGLED NAMESTITVE .................................................................................................... 7
3. SHEMA NAMESTITVE ......................................................................................................... 8
4. SPECIFIKACIJE .................................................................................................................. 9
5. NAMESTITEV ZUNANJE ENOTE ..................................................................................... 10
5.1 Navodila za namestitev zunanje enote ................................................................................................ 10
5.2 Namestitev odtočnega priključka ......................................................................................................... 12
5.3 Opombe glede vrtanja luknje v steno .................................................................................................. 12
5.4 Izbira notranje enote 24K ...................................................................................................................... 12
6. PRIKLJUČITEV CEVI HLADILNEGA SREDSTVA ............................................................ 13
7. NAPELJAVA ...................................................................................................................... 15
7.1 Varnostna opozorila ............................................................................................................................... 15
7.2 Napeljava zunanje enote ....................................................................................................................... 15
7.3 Shema napeljave .................................................................................................................................... 17
8. ODVAJANJE ZRAKA ........................................................................................................ 20
8.2 Navodila za odvajanje zraka ................................................................................................................. 20
8.4 Opomba glede dodajanja hladilnega sredstva .................................................................................... 21
9. PREIZKUS DELOVANJA ................................................................................................... 22
10. FUNKCIJA ZA SAMODEJNO ODPRAVLJANJE NAPAK ELEKTRIČNE
NAPELJAVE/CEVI ........................................................................................................... 23
11. PODATKI O SERVISIRANJU ........................................................................................... 24
Tip Ime modela Dimenzija(ODU) Nazivna napetost in Hz
Zunanja enota
38QUS014DS2*
38QUS018DS2-2/38QUS018D8S2
800x333x554
220-240V~ 50Hz
38QUS018DS2*
38QUS021DS3*
38QUS027DS3*/38QUS027D8S3*
845x363x702
38QUS028DS4*
38QUS036DS4*/38QUS036D8S4*
38QUS042DS5*/38QUS042D8S5*
946x410x810
Stenska
notranja enota
42QHC007DS*/42QHC007D8S*
42QHC009DS*/42QHC009D8S*
730×192×291
42QHC012DS*/42QHC012D8S* 812×192×300
42QHC018DS*/42QHC018D8S* 973×218×319
42QHC024DS*/42QHC024D8S* 1082×225×338
Tip lepilnega traku
Notranja enota
42QSS009DS*
42QSS012DS*
700x635x210
42QSS007D8S*
42QSS009D8S*
42QSS012D8S*
700×450×200
42QSS018DS*/42QSS018D8S* 880x674x210
42QSS024DS*//42QSS024D8S* 1100x774x249
Tip kasete
Notranja enota
42QTD007DS*
42QTD009DS*/42QTD009D8S*
42QTD012DS*/42QTD012D8S*
42QTD018DS*/42QTD018D8S*
570x570x260
42QTD024DS* 840x840x245
Tip konzole
Notranja enota
42QZA009DS*
700x600x21042QZA012DS*/42QZA012D8S*
42QZA018DS*
