Carrier 42QHC024D8S Series - Page 12

5. OUTDOOR UNIT INSTALLATION
7GB-11
Table 5.1: Length Specifications of Split
Type Outdoor Unit (unit: mm)
Split Type Outdoor Unit
(Refer to Fig 5.4, 5.5, 5.6, 5.9 and Table 5.1)
Fig. 5.5
A
D
W
H
Fig. 5.4
Outdoor Unit Dimensions
W x H x D
Mounting Dimensions
Distance A Distance B
946x810x420 (37.2x31.9x16.53) 673
403
946x810x410 (37.2x31.9x16.14) 673
403
845x702x363 (33.27x27.6x14.3)
540
350
800x554x333 (31.5x21.8x13.1) 514 340
Rows of series installation
L ≤ H
L ≤ 1/2H
LA
25 cm / 9.8” or more
1/2H < L ≤ H 30 cm / 11.8” or more
L > H
Can not be installed
Table 5.2 The relations between H, A and
L are as follows.
Fig. 5.6
L
H
300 cm / 118” or more
A
60 cm / 23
.6”
or more
150 cm / 59”
or mo
r
e
25 cm /
9.8”
or more
25 cm / 9.8”
or more
B
