Carrier A Series - Page 14

PG80VTLA: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
14
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 605 555 500 440 375 320 265 See Note 4
OFF ON OFF 775 735 690 650 600 550 500 450 405 365
OFF ON ON 980 950 915 880 845 810 775 735 695 655
ON OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
ON OFF ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON OFF 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
ON ON ON 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
Cont. Fan
Default:
OFF OFF OFF 605 555 500 440 375 320 265 See Note 4
Continuous
Fan
(SW2-5,4,3)
OFF OFF ON 605 555 500 440 375 320 265 See Note 4
OFF ON OFF 775 735 690 650 600 550 500 450 405 365
OFF ON ON 980 950 915 880 845 810 775 735 695 655
ON OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
ON OFF ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON OFF 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
Heating
(SW1)
High Heat Airflow3 1190 1160 1130 1100 1070 1045 1015 985 955 900
Low Heat Airflow3 725 680 635 585 530 475 425 375 330 285
Unit Size:
48070B
Clg/CF Switch settings External Static Pressure (ESP)
Clg
Switches:
SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
Cooling
(SW2-8,7,6)
OFF OFF ON 590 520 440 365 300 235 See Note 4
OFF ON OFF 790 730 670 610 550 485 430 380 330 275
OFF ON ON 1025 980 930 880 835 785 735 690 635 590
ON OFF OFF 1230 1190 1150 1105 1065 1025 980 940 900 860
ON OFF ON 1390 1355 1315 1280 1240 1200 1165 1125 1090 1055
ON ON OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
ON ON ON 1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
Maximum Clg Airflow
2
1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
CF Switches SW2-5 SW2-4 SW2-3
Low-Clg
Default:
OFF OFF OFF 590 520 440 365 300 235 See Note 4
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 590 520 440 365 300 235 See Note 4
OFF ON OFF 790 730 670 610 550 485 430 380 330 275
OFF ON ON 1025 980 930 880 835 785 735 690 635 590
ON OFF OFF 1230 1190 1150 1105 1065 1025 980 940 900 860
ON OFF ON 1390 1355 1315 1280 1240 1200 1165 1125 1090 1055
ON ON OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
ON ON ON 1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
Cont. Fan
Default:
OFF OFF OFF 590 520 440 365 300 235 See Note 4
Continuous
Fan
(SW2-5,4,3)
OFF OFF ON 590 520 440 365 300 235 See Note 4
OFF ON OFF 685 625 565 505 445 385 325 265 See Note 4
OFF ON ON 790 730 670 610 550 485 430 380 330 275
ON OFF OFF 790 730 670 610 550 485 430 380 330 275
ON OFF ON 790 730 670 610 550 485 430 380 330 275
ON ON OFF 790 730 670 610 550 485 430 380 330 275
ON ON ON 790 730 670 610 550 485 430 380 330 275
Heating
(SW1)
High Heat Airflow
3
1410 1375 1340 1300 1260 1225 1190 1155 1120 1085
Low Heat Airflow
3
1235 1195 1155 1110 1070 1025 985 945 905 865
Table 4 – Air Delivery - CFM (With Filter)* (Continued)
COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
With Filter)
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
