Carrier Omnizone 50BVC User Manual

11
Fig. 7 — 50BVC,J,Q020-034 Dimensions
HEIGHT
7.00
28.00
10.00
34.00
34.00
4.50
28.00
2.00
17.50
C
B
A
80.00
32.00
BLOWER MOTOR
ORIENTATION
CONDENSER WATER OUT
CONDENSATE DRAIN
CONDENSER WATER IN
ELECTRICAL
CONNECTIONS
D
E
6.0
9.0
20.0
24.0
14.0
22.0
34.00
34.00
4.50
22.00
BLOWER
MOTOR
ORIENTATION
17.50
2.00
28.00
10.00
28.00
7.00
6.00
9.00
20.00
24.00
14.00
E
D
HEIGHT
C
B
A
CONDENSER WATER OUT
CONDENSATE DRAIN
CONDENSER WATER IN
80.00
32.00
ELECTRICAL
CONNECTIONS
OPTIONAL BLOWER
ORIENTATION
STANDARD BLOWER
ORIENTATION
OPTIONAL BLOWER
ORIENTATION
STANDARD BLOWER
ORIENTATION
FRONT RETURN
REAR RETURN
TOP SUPPLY
REAR SUPPLY
FRONT SUPPLY TOP SUPPLY
* When WSHP Open controller is installed increase depth by 3.00
inches.
NOTES:
1. All dimensions in inches unless otherwise noted. All dimensions
within ± 0.125-in. Specifications subject to change without notice.
Condensate connections are 1.25 in. FPT on sizes 020 through
034.
2. Front of unit is side with water and electrical connections.
UNIT
SIZE
HEIGHT WIDTH DEPTH*
CONDENSER WATER CONNECTIONS
DUCT
FLANGE
FILTER
RACK
REPLACEMENT FILTER
SIZE (NOMINAL)
ABC
DIAMETER
(FPT)
DE
020 62.00 80.00 32.00 18.00 8.75 2.75 2 40.00 38.00
20 x 34
1
/
2
x 1
(4 per unit)
30 x 34
1
/
2
x 1
(4 per unit, size 360 only)
040 66.50 80.00 32.00 18.00 8.75 2.75 2 40.00 38.00
028 66.50 80.00 32.00 18.00 8.75 2.75 2 40.00 38.00
034 86.50 80.00 32.00 17.00 9.00 3.50 2 60.00 58.00
