Fig. 8 — 50BVT,V,W034 (High-Boy) Dimensions
Rear Return, Front Supply with Waterside Economizer and Hot Water Coil
REAR VIEW
RETURN AIR VIEW
LEFT SIDE VIEW
FRONT VIEW
54.38
EVAPORATOR
ACCESS
BLOWER
SECTION
ACCESS
LEFT SIDE VIEW
FILTER ACCESS
DX EVAPORATOR
FRONT
DISCHARGE
COMPRESSOR
ACCESS
COMPRESSOR
ACCESS
EVAPORATOR
ACCESS
EVAPORATOR
ACCESS
ACTUAL
16.5 X 29.75
Drain*
Pre-Cooling
Condensate*
H2O OUT*
H2O IN*
1.25
WATER CONNECTIONS
NOMINAL
17 X 30
1.25
2.5
2.5
FILTERS
**4 INCHES THICK
QUANTITY
*F.P.T. Type Connection
NOTE:
(1) Optional hot water coil connections may add up to
3" on both the left and right side of the unit increasing
the unit width an additional 6".
8
LIFTING SUPPORT RAIL
1.50
CONDENSATE
DRAIN
WATER OUT
31.00
10.95
15.00
51.63
LOW
VOLTAGE
HIGH
VOLTAGE
CONTROL BOX
ELECTRICAL
BOX
ELECTRICAL
BOX
ACCESS
112.50
2.00
VFD
BOX
BLOWER
SECTION
ACCESS
23.95
18.95
49.95
21.95
9.88
81.50
69.50
OPTIONAL ECONO. COIL
2.88
8.95
13.00
5.00
WATERSIDE ECONOMIZER
DRAIN
WATERSIDE ECONOMIZER
WATER IN
OPTIONAL HOT WATER COIL
HOT WATER OUT
HOT WATER IN
23.25
HW IN/OUT
SWEAT
CONNECTION
1.38
BLOWER SECTION
REMOVABLE FOR
SHIPPING
BLOWER SECTION
REMOVABLE FOR
SHIPPING
SEE NOTE (1)
HOT GAS REHEAT COIL
WATER IN
3.95
