Carrier Omnizone 50BVC User Manual

15
Fig. 11 — 50BVT,V,W044-064 (Low-Boy) Dimensions
Rear Return, Front Supply with Waterside Economizer and Hot Water Coil
ACTUAL
16.5 X 29.75 X 4
NOMINAL
17 X 27 X 4
FILTERS
QUANTITY
*
16
SEE NOTE (4)
WATER CONNECTIONS
44 54 64
H2O IN* 2.5 3.0 3.0
H2O OUT* 2.5 3.0 3.0
1.25 1.25 1.25
1.25 1.25 1.25
HW IN/OUT SWEAT
CONNECTION
1.38 1.3 8 1.38
COMPRESSOR
ACCESS
COMPRESSOR
ACCESS
COMPRESSOR
ACCESS
COMPRESSOR
ACCESS
COMPRESSOR
ACCESS
REMOVABLE
FOR SHIPPING
REMOVABLE
FOR SHIPPING
CONTROL BOX
ELECTRICAL BOX
ELECTRICAL BOX
ACCESS
ELECTRICAL BOX
ELECTRICAL BOX
ACCESS
FILTER
ACCESS
EVAPORATOR
ACCESS
VFD
BOX
BLOWER
SECTION
ACCESS
FILTER ACCESS
OPTIONAL ECONO. COIL
HOT WATER OUT
DX EVAPORATOR
OPTIONAL HOT WATER COIL
CONDENSATE
DRAIN
WATER OUT
PRE-COOLING
DRAIN
WATER IN
HOT WATER IN
PRE-COOLING DRAIN*
CONDENSATE*
MODEL
F.P.T. TYPE CONNECTION
DX EVAPORATOR
FILTER ACCESS
OPTIONAL ECONO. COIL
NOTES:
1. Dimensions in inches [mm].
2. Recommended minimum service clearances are as
follows:
a. Front and rear — 30 [762]
b. Left or right side — 65 [1651] for coil removal
3. For all other airflow configuration drawings, see
SCUBuilder program.
4. Dimensions include base rail height (1.5 in.).
