Carrier Omnizone 50BVC User Manual

16
Fig. 12 — 50BVC,J,Q020-028 Front Return, Top Supply with Optional Waterside Economizer
4.25
[108]
4.00
[102]
8.00
[203]
23.93
[608]
A
LEFT SIDE VIEW
B
DRAIN
32.00
[813]
AIR
AIRAIR
40.00
[1016]
5.00
[127]
17.25
[438]
34.50
[876]
4.00
[102]
0.75
[19]
DRAIN
D
MOTOR AND BLOWER
ACCESS (BOTH SIDES)
RIGHT SIDE VIEW
VFD
2.50
[64]
19.00
[483]
4.00
[102]
1.00
[25]
2.75
[70]
C
3.25
[83]
[83]
4.75
[121]
FRONT VIEW
8.75
[222]
COMPRESSOR
ACCESS
CONTROL BOX
AND
CONTROLLER
ACCESS
HIGH
VOLTAGE
LOW
VOLTAGE
WATER
OUT
DRAIN
WATER
IN
14.00
[356]
7.25
[184]
10.00
[254]
TOP VIEW
2.00
[51]
32.00
[813]
FILTER RACK
80.00
[2032]
9.00
[229]
24.00
[610]
14.00
[356]
24.00
[610]
20.00
[508]
2" FPTWATER CONN. 2" FPT2" FPT
CONDENSATE CONN. 1-1/4" FPT 1-1/4" FPT 1-1/4" FPT
FILTER QTY. & SIZE
(4) 17 x 34-1/2 x 1"
B
D
A
C
66.5"
18.75"
35"
32"
62" 66.5"
18.75"
35"
32"
17.5"
31"
28"
(4) 17x 34-1/2 x 1" (4) 17x 34-1/2 x 1"
SIZE
020 024 028
NOTES:
1. Dimensions in inches [mm].
2. Refer to base unit certified drawing for additional unit dimensions,
service clearance, and alternate airflow configurations.
3. For all other airflow configuration drawings see SCUBuilder program.
4. 50BVJ are Rear Return, Top Supply only.
