17
Fig. 13 — 50BVC,J,Q 034 Front Return Top Supply with Optional Waterside Economizer
WATER CONN. 2" FPT
CONDENSATE CONN. 1-1/4" FPT
FILTER QTY. & SIZE
(4) 27" x 34-1/2" x 1"
SIZEDESCRIPTION
8.00
[203]
LEFT SIDE VIEW
DRAIN
32.00
[813]
13.50
[343]
1.50
[38]
33.25
[845]
38.50
[978]
0.75
[19]
1.00
[25]
13.50
[343]
7.50
[190]
FRONT VIEW
14.00
[356]
21.00
[533]
18.88
[479]
3.50
[89]
2.75
[70]
5.50
[140]
8.75
[222]
80.00
[2032]
3.50
[89]
5.00
[127]
COMPRESSOR
ACCESS
CONTROL BOX
AND
CONTROLLER
ACCESS
WATER
OUT
DRAIN
WATER
IN
LOW
VOLTAGE
HIGH
VOLTAGE
10.00
[254]
TOP VIEW
2.00
[51]
32.00
[813]
FILTER RACK
20.00
[508]
24.00
[610]
24.00
[610]
9.00
[229]
14.00
[355]
AIR
MOTOR AND BELT ACCESS
(BOTH SIDES)
AIRAIR
61.00
[1549]
6.00
[152]
DRAIN
86.50
27.25
[692]
54.50
[1384]
3.50
[89]
5.25
[133]
VFD
2.50
[64]
19.00
[483]
4.00
[102]
1.00
[25]
RIGHT SIDE VIEW
NOTES:
1. Dimensions in inches [mm].
2. Refer to base unit certified drawing for additional unit dimensions,
service clearance, and alternate airflow configurations.
3. For all other airflow configuration drawings see SCUBuilder program.
4. 50BVJ are Rear Return, Top Supply only.
