12
2-2. Front Panel Descriptions.
(1) Main Display (Weight Display)
A. Displaying the value of gross or net weight.
B. Displaying error messages for any abnormal motion or weigh setup error/
C. Displaying the status value for the Set Mode and weight setup mode.
(2) Status Display (Lamp)
LED Lamp Descriptions
Stable
The weighed weight is stable.
NET
The current display of weight is a net weight.
Zero point
The current weight is 0 kg.
Communication
The current status is at the communication status.
(3) Keyboard
* It sets the weight display near zero point to 0.
( A range of 2%, 5%, 10%, 20% and 100% can be selected.)
* Use it to weigh with the tare.
* The current weight is memorized as the tare by pressing the key.
* Press the key when the load tray is empty to release the tare.
* Use it to save the current status and exit from the Function mode.
* Use it to power on/off.
* Function mode, : CAL MODE, SET MODE, TEST MODE
