1. Features
1-1. Features
Suitable for the Checkout scale and weighing system
Easy operations
Simple and prompt full digital calibration (automatic weight setup at once)
Weight backup functions [restoring weight at the power supply On/Off]
Multiple weights setup functions [5 point input weight setup]
Command Mode [ ECR Protocol]
6 line [basic] / 4 line load cell Input
1-2. Major Functions
Free to set the maximum weight and a division value as a user desires
Independent zeroing functions
Compatible various ECR.
1-3. Analog and A/D Conversion
Applied voltage for load cell
DC 5V (350Ω maximum 8 possible connections)
Zeroing range
0 ~ 2mV/V
0.5 uV / D (OIML, )Ntep, KS
Input sensitivity
0.5 uV / D (Non OIML, )Ntep, KS
Non-straightness
0.01% Full Scale
A/D internal resolution
1 / 520,000
1 / 10,000 (NTEP, )OIML, KS
A/D external resolution
1 / 20,000 (Non NTEP, )OIML, KS
(Possible with the use of sufficient output at 2mV/V L/C)
A/D conversion speed
Maximum 80 rounds/second
Weight setup
Full Digital Calibration : SPACTM
(Automatic weight setup at once)
