6 - FIELD OPERATION
217
STRAW SPREADERS AND STRAW/CHAFF SPREADERS
Cone Removal
The straw spreaders and straw/chaff spreaders
distribute the straw from the beater evenly over the
ground. This helps to prevent bunching and
windrowing, making plowing and tillage operations
easier.
For better windrowing when the straw is to be baled,
remove the spreaders (Refer to Baling Straw in this
section of the manual).
NOTE: Always clean the shafts and apply a dry
lubricant (Slip Plate) on the shafts before installing
the cones.
To remove the curved bat straw/chaff spreaders,
depress large button and drop spreader off of
shaft.
To remove the straw/chaff spreaders, depress
large button and drop spreader off of shaft.
NOTE: DO NOT lubricate couplings. Oil and grease
accumulate dust which causes binding.
WARNING: Avoid injury from rotating
spreader or thrown material. Do not stand
behind Combine when the spreader is
turning.
M191A
RD01D200
CURVED BAT STRAW/CHAFF SPEADER
!
