6 - FIELD OPERATION
219
Straw Directional Vane
The straw directional vane is standard with the
straw/chaff spreader. The straw directional vane
controls the amount of straw directed to each
straw/chaff spreader disc.
For more left side discharge of straw, move the vane
to the left hole.
For more right side discharge of straw, move the
vane to the right hole.
RD00E033
13
