9 - MAINTENANCE/ADJUSTMENTS
402
Adjustable Strippers
Adjustable strippers reduce the build up of material
at the feeder conveyor sprockets. Adjust the
strippers as follows:
1. Remove the upper top cover (1) from the feeder.
2. Loosen the two stripper retainer bolts for each
stripper (2).
3. Move each stripper until the sprocket is centered
in this slot and the sprocket teeth are a minimum
of 0.8 mm (1/32 inch) from the strippers.
4. Tighten the retainer bolts and install the feeder
top cover (1).
Perforated Feeder Bottom (Parts
Accessory)
The perforated feeder bottom sheet will permit dirt
to pass through the perforations instead of into the
Combine when harvesting edible beans and peas.
See your dealer.
RD97G168
RD97G167
1
2
212L7
PERFORATED FEEDER BOTTOM SHEET
