CDP-120
– 12 –
A-8. Undo three screws on the RIGHT-SIDE-CASE and then remove the RIGHT-SIDE-CASE.
RIGHT-SIDE-CASE
A-9. Undo three screws on the LEFT-SIDE-CASE and then remove the LEFT-SIDE-CASE.
LEFT-SIDE-CASE
